EcoFlow Power Hub(with Cable Pack)

FREE SHIPPING

$ 2,99800

 More payment options

Introducing the EcoFlow Power Hub(with Cable Pack), a game-changer in portable power solutions. It's the heart of Power Kits with a 3600W AC continuous output (7200W surge).

One of the primary functions of an EcoFlow Power Hub(with Cable Pack) is to convert DC (direct current) power, typically from a battery source like a lithium-ion battery, into the appropriate type of power for various devices. This conversion may include transforming DC power into AC (alternating current) power for devices that require AC power, such as laptops or household appliances, or converting it into DC power for devices like smartphones or tablets.

The EcoFlow Power Hub(with Cable Pack) has lightning-fast recharging capability. Utilizing advanced MPPT technology, it efficiently converts solar energy into power, enabling you to recharge the battery quickly and efficiently when connected to compatible solar panels.

The EcoFlow Power Hub(with Cable Pack) has a 3600W AC output and includes two MPPT solar charge controllers, a DC-DC battery charger with MPPT, an inverter charger, and a DC-DC step-down converter. Everything you need to power your tiny home or van.

Overall, the role of an EcoFlow Power Hub(with Cable Pack) is to empower individuals by providing a reliable, portable, and centralized source of power. It ensures that devices and appliances can be powered and charged conveniently in various settings, enabling productivity, connectivity, and peace of mind in situations where power is essential.

FREE SHIPPING on this item anywhere in the lower 48 US states.

Key Features: EcoFlow Power Hub(with Cable Pack)

  • The heart of Power Kits with a 3600W continuous AC output (7200W surge)
  • 5 components in 1 ( 2x MPPT solar chargers, 1x DC-DC battery charger with MPPT, 1x Inverter-charger, and 1x DC-DC converter
  • Built-in Wi-Fi and Bluetooth
  • Direct 2400W AC outlet
  • Made in China
  • 5-year warranty


What's Included?

  • EcoFlow Power Hub (Gen 1)
  • EcoFlow Power Kit Cable Pack (Gen 1)
  • 2x Mounting Brackets

Specifications: EcoFlow Power Hub(with Cable Pack)

Brand EcoFlow
Type Power Hub
DC Main Output 13.6V 70A or 26.4V 60A
AC Main Output 100V~120V 50Hz or 60Hz, 3600W (7200W Peak) (3000W @ Battery Voltage < 50V)
Auxiliary AC Outlet 100V~120V 20A
Total Input Power Max. 6000W
AC Input Power 100V~120V Max.30A, Max. 3000W
Alternator Input Power Port 1: 13V~60V 60A, Max. 1600W
Port 2 & 3: 13~60V 30A, Max. 1600W Each
Solar Input Power Port 1 & 2 & 3: 15V~60V 30A, Max. 1600W Each
Dimension (HxWxD) 11.8 in X 18.9 in X 5.5 in
Operating Temperature -13°F to 140°F
Net Weight 31 lbs
Certificate & Standard CE, UL, FCC, UKCA, E-Mark, RCM,
TELEC, KCC, ICES, EMC Class A
Warranty 5 Years


Document: EcoFlow Power Hub

EcoFlow Power Hub User Manual

Videos: EcoFlow Power Hub


FAQ

How does the Power Hub communicate the voltage to the Smart Distribution panel?

There are two included RJ45 network cables included in a Independence Power Kit. One that connects the Power Hub directly to the Smart AC/DC Distribution Panel; a second one to connect the Power Hub to the Power Kit Console.

What is the operating temperature range of the Power Kit Console?

The information as stated in the user manual is below: -20C to 50C (-4F to 122F). This is the operating temperature range for all
Power Kit components.

What is considered a standard alternator input scenario and what is else is allowed involving alternator charging with EcoFlow Power Kits?

All 3x PV/ALT input ports can be used as alternator charging ports. The first ATL-IN input port can allow 70A max and 1600W input max, meaning that if you draw from 12V alternator you can only get 13.6V x 70A = 952W which is almost 1000 (it will fluctuate between 950W and 1000W). If a 48V alternator is connected to port 1, then an estimated 54V x 29.6A = 1600W is expected. The 2nd and 3rd ALT-IN input ports are both 30A max and 1600W max. If you connect a 12V alternator to these ports, an estimated 13.6V x 30A = 408W each is expected. If you connect a 48V alternator to ALT-IN 2 or 3 ports, an estimated 54V x 29.6A = 1600W each is expected. If you connect a 12V alternator on all 3 ALT-IN input ports, an estimated 952W + 408W + 408W = 1768W (if your 12V alternator can deliver 70A + 30A + 30A = 130A) is expected. If you use 48V alterantor on all 3 ports, an estimated 1600W + 1600W + 1600W = 4800W input is expected.

What type of shore power inlet is recommended for an EcoFlow Power Kit?

The Power Kit allows up to 30A input, so we recommend 30amps max. 30A to 15A converters are available if your enegy consumption needs are not high. Furrion is a tested and trusted brand that has worked perfectly with an EcoFlow Power Kit.
