EcoFlow Home Backup Transfer Switch A510A 50A (DELTA Pro Ultra/Pro ...
Need a way to connect your DELTA Pro Ultra to your home's main panel for home backup power? The EcoFlow Home Backup Transfer Switch A510A 50A (DELTA Pro Ultra/Pro 3/3 Plus) is a 50-amp, 10-circuit manual transfer switch with a L14-30/L5-30 power inlet and wattmeters, providing you with a seamless and secure backup power system.
This transfer switch integrates perfectly with the EcoFlow DELTA Pro Ultra, offering a simple, safe, and sustainable setup for your backup power needs. Working with a licensed electrician, you can easily select up to 6 essential circuits from your breaker panel to stay powered in the event of an outage, ensuring that your most critical appliances and devices stay powered during blackouts.
The EcoFlow Home Backup Transfer Switch A510A 50A (DELTA Pro Ultra/Pro 3/3 Plus) gives you the flexibility to choose circuits such as your fridge, garage door, outlets in main living areas, light switches, and more; you can customize your backup system to suit your specific needs. For the ultimate power security, we highly recommend pairing this switch with the EcoFlow DELTA Pro Ultra home battery backup system.
Safety is our top priority, and that's why the EcoFlow Home Backup Transfer Switch A510A 50A (DELTA Pro Ultra/Pro 3/3 Plus) is cULus 1008 listed, providing a safe and trustworthy backup power solution for your valuable electronics and appliances. It is compatible with any UL-listed 1” interchangeable circuit breaker and can easily be reconfigured in the field for multiple double-pole circuits, if necessary. Additionally, the switch comes with a swing-up protective cover that not only provides added safety but also gives a polished and finished appearance.
Say goodbye to noisy and smoky generators with this clean and silent power alternative. The EcoFlow Home Backup Transfer Switch A510A 50A (DELTA Pro Ultra/Pro 3/3 Plus), when paired with the EcoFlow DELTA Pro Ultra, delivers a fume-free and quiet power supply, revolutionizing the way you deal with power outages. Unlike traditional gas generators, DELTA Pro portable power stations can be used both indoors and outdoors, allowing you to run all your essentials without any disruptions during a blackout. Moreover, you could recharge your DELTA Pro batteries using solar energy during extended outages, making it an environmentally friendly and sustainable choice.
Don't be caught unprepared during the next blackout. Invest in the EcoFlow Home Backup Transfer Switch A510A 50A (DELTA Pro Ultra/Pro 3/3 Plus) as part of an EcoFlow home backup solution and enjoy the peace of mind that comes with a reliable, safe, and silent backup power solution for your home.
FREE SHIPPING on this item anywhere in the lower 48 US states.
Key Features: EcoFlow Home Backup Transfer Switch A510A 50A (DELTA Pro Ultra/Pro 3/3 Plus)
- Completely pre-wired for easy installation
- Eliminates the dangers associated with back-feeding
- Cover included to protect toggle switches and circuit breakers
- Powder-coated steel cabinet, designed for indoor use
- Includes color-coded wattmeters and an L14-30 power inlet
- UL1008 listed, IP67-rated
-
(6) 15A 1-pole, (1) 20A 2-pole, and (1) 30A 2-pole
-
Eliminates dangerous backfeeds and electrical overloads
-
Allows hardwiring OR plug-in connection via power inlet (included)
-
Protects toggle switches/breakers & provides a finished appearance
-
18" Flexible conduit w/ all factory wires clearly marked/colored
-
(6) Combination 1/2" & 3/4" knockouts for easier installation
-
Easily re-configured in the field for multiple 2-pole circuits
- Made in China
- 5-year warranty.
Note: Requires a qualified electrician for installation. Only viable with indoor circuit breaker panels.
What's Included:
- (1) Transfer Switch
- (1) User Manual
- (1) Ecoflow Power Station Connection Cable
Specifications: EcoFlow Home Backup Transfer Switch A510A 50A (DELTA Pro Ultra/Pro 3/3 Plus)
| Voltage | 125/250V |
|---|---|
| Amps | 50A |
| Circuits | 10 |
| Enclosure | Metal |
| Color | Gray |
| Dimensions (W x H x D) |
11.75 x 4.5 x 11 inches |
| Weight (Transfer Switch only) | 20 lbs |
| Power Inlet, NEMA | NEMA L14-30 |
| Maximum Watts | 3750 / 7500 |
| Frequency | 60 Hz |
| Circuit Breaker Protection |
Each Circuit |
| Standards | IP67, UL1008, Article 702 (NFPA70) |
Documents: EcoFlow Home Backup Transfer Switch A510A 50A (DELTA Pro Ultra/Pro 3/3 Plus)
ProTran2 Installation and Operating Instructions
Video: EcoFlow Home Backup Transfer Switch A510A 50A (DELTA Pro Ultra/Pro 3/3 Plus)
FAQ
FAQ
How does the Power Hub communicate the voltage to the Smart Distribution panel?
There are two included RJ45 network cables included in a Independence Power Kit. One that connects the Power Hub directly to the Smart AC/DC Distribution Panel; a second one to connect the Power Hub to the Power Kit Console.
What is the operating temperature range of the Power Kit Console?
The information as stated in the user manual is below: -20C to 50C (-4F to 122F). This is the operating temperature range for all
Power Kit components.
What is considered a standard alternator input scenario and what is else is allowed involving alternator charging with EcoFlow Power Kits?
All 3x PV/ALT input ports can be used as alternator charging ports. The first ATL-IN input port can allow 70A max and 1600W input max, meaning that if you draw from 12V alternator you can only get 13.6V x 70A = 952W which is almost 1000 (it will fluctuate between 950W and 1000W). If a 48V alternator is connected to port 1, then an estimated 54V x 29.6A = 1600W is expected. The 2nd and 3rd ALT-IN input ports are both 30A max and 1600W max. If you connect a 12V alternator to these ports, an estimated 13.6V x 30A = 408W each is expected. If you connect a 48V alternator to ALT-IN 2 or 3 ports, an estimated 54V x 29.6A = 1600W each is expected. If you connect a 12V alternator on all 3 ALT-IN input ports, an estimated 952W + 408W + 408W = 1768W (if your 12V alternator can deliver 70A + 30A + 30A = 130A) is expected. If you use 48V alterantor on all 3 ports, an estimated 1600W + 1600W + 1600W = 4800W input is expected.
What type of shore power inlet is recommended for an EcoFlow Power Kit?
The Power Kit allows up to 30A input, so we recommend 30amps max. 30A to 15A converters are available if your enegy consumption needs are not high. Furrion is a tested and trusted brand that has worked perfectly with an EcoFlow Power Kit.
